Elac Uni-Fi 2.0 UC52 Center Channel Speaker - Black Ash

Uni-Fi 2.0 UC52 Center Speaker

The Centre of Attention. The center channel is the most critical speaker in a surround sound system. The UC52's concentric driver provides the perfect solution for a compelling home theater experience. Using the same outstanding drivers and technology as the other models in the series ensures this compact, 3-way, bass-reflex center speaker delivers a matched sonic signature.

Key Features:
- Newly Developed Concentric Driver - a new wide-surround tweeter enhances low and high frequency extension for improved blending with the midrange driver, while the entirely new mid-range design features a larger diameter voice coil, new aluminum cone profile, new low-profile surround and an all-new neodymium magnet assembly
- New Single Piece Woofers - newly developed single piece aluminum dished cones result in improved stiffness; combined with an oversized magnet, large diameter voice coil, and extended pole piece, these changes result in improved accuracy and bass dynamics
- Sophisticated 3-Way Crossover - an enhanced design improves response linearity, improves driver integration and delivers a true 6-ohm nominal impedance for compatibility with virtually all AV receivers
- Front Firing Vents - relocating the vents to the front allows for greater freedom of placement, even in restricted places like a cabinet
- Enhanced Bracing - thick MDF outer walls and a luxurious black ash vinyl finish, with specially located internal bracing reducing cabinet vibration

Specifications:
Speaker Type - 3-Way, Bass Reflex
Tweeter - 1" soft dome, concentrically mounted
Midrange - 1x 4" aluminum cone
Woofer - 2x 5.25" aluminum cone
Crossover Frequency - 200 / 2000 Hz
Frequency Response - 48-35000Hz
Sensitivity - 85 dB/2.83V/m
Recommended Amplifier Power - 40-140W/channel
Peak Power Handling - 140W
Nominal Impedance - 6Ω
Binding Posts - 5-Way custom
Cabinet Finish - Black ash vinyl
Height x Width x Depth - 185 x 543 x 274 mm
Weight - 11.66 kg
